PACKAGE CAPACITOR 12.5/20kVAR 400/525V + 7% DETUNED REACTOR

Download the CAPCDR125 PACKAGE CAPACITOR 12.5/20kVAR 400/525V + 7% DETUNED REACTOR product datasheet, by clicking here!

Technical Characteristic:

• Product Code : CAPCDR125
• Brand : Schneider Electric
• Product Name : PACKAGE CAPACITOR 12.5/20kVAR 400/525V + 7% DETUNED REACTOR
• Description : PACKAGE VARPLUS CAN (525V)+DETUNED REACTOR - CAPCDR125
• Range of Product : PowerLogic
• Connections - Terminals : ClampTite terminal
• Height : Capacitor: 242 mm & Detuned Reactor: 220 mm
• Reactive Power Rating : 12.5 kvar for 400 V AC 50 Hz
• Range : PowerLogic
• Device short name : DR
• Product Hover Image : /s/c/screenshot_2023-06-27_092751.jpg
• Product or Component Type : heavy duty capacitor, detuned reactor
• Net weight : Capacitor: 2.5 kg Detuned Reactor: 10 kg
• Series Name : HDuty
• Diameter : Capacitor: 116 mm
• Dielectric Material : Metallized polypropylene film with Zn/Al alloy, special resistivity & profile, special edge (wave cut)
• Network frequency : 50/60 Hz (Capacitor) & 50 Hz (Detuned Reactor)
• Network Harmonic Content  : <= 20%
• Maximum Permissible Voltage : 1.1 x Un (8 hours over 24 hours)
• Rated Voltage : 525 V AC 50/60 Hz
• Network Rated Voltage : 400 V AC 50 Hz
• Tuning Order : 3.8 - 190 Hz - 7 % - 50 Hz

Schneider Electric Package VarPlus Can HDuty Capacitor

CAPCDR125 package is combination of 1-unit PowerLogic PFC Capacitor BLRCH200A240B52 with 1-unit Detuned Reactor LVR07125A40T for 12.5 kVAR @400V AC network. CAPCDR125 provides complete yet simple selection of power factor correction solution along with its protection on harmonic amplification in the system to ensure greatest product performance and safety of your electrical panel.
