MCCB + ELCB 3P VIGI TM100D 70KA 380/415VAC

To download the product datasheet C11H34V100B MCCB + ELCB 3P VIGI TM100D 70KA 380/415VAC, please click here!

Technical Characteristic:

• Product Code : C11H34V100B
• Brand : Schneider Electric
• Product Name : MCCB + ELCB 3P VIGI TM100D 70KA 380/415VAC
• Description : NEW COMPACT NSXM + ELCB COMPRESSION LUG / BUSBAR CONNECTORS SCHNEIDER ELECTRIC - C11H34V100B
• Range : ComPacT new generation
• product name : ComPacT NSXm new generation
• Product or component type : Earth leakage circuit breaker
• Number of poles : 3P
• [In] rated current : 100 A at 40 °C
• [Ue] rated operational voltage : 440 V AC 50/60 Hz
• Trip unit name : MicroLogic 4.1
• Trip unit technology : Electronic
• Control type : Toggle
• Power dissipation per pole : 4.8 W
• Width (W) : 108 mm
• Height (H) : 144 mm
• Depth (D) : 80 mm
• Product weight : 1.63 kg
• Colour : Grey (RAL 7016)

Schneider Electric ComPacT NSXm new generation

The new generation of ComPacT circuit-breakers breakers feature an innovative all-in-one design. With time- and cost-saving installation and greater connectivity, with their new wireless auxiliaries, they will be a perfect fit for all your projects. ComPacT NSXm molded case circuit breakers (MCCB) come in one size and are optimized for small spaces.

• Rated currents: 16 to 160 A
• 95 breaking capacity levels
• 3 or 4 poles
• Thermal-magnetic protections
• Residual current protection option integrated in the circuit-breaker
• Built‑in DIN rail and plate mount capability, able to operate in any installation position
• EverLink™ connectors for bare cables
• Field‑installable and spring-type auxiliaries externally visible
